Liu machine (Wuling Liu machine) production, in-line four-cylinder, water-cooled, four-stroke, overhead camshaft, toothed belt drive, multi-point electronic control gasoline injection micro-gasoline engine, it is widely used face, micro-card (Wuling light, Xingwang, Hafei Zhongyi, FAW Jiabao, etc.).
Core technical parameters
- Cylinder arrangement: 4 cylinders in line, inclined arrangement
- Bore × stroke: 65. 5 mm × 78 mm
- Displacement: 1. 051 L(1051cc)
- Compression ratio: 9.0: 1
- Valve distribution: sohc overhead camshaft, 2 valves per cylinder, belt drive
- Fuel supply: electronically controlled multi-point sequential injection
- Rated power: 38. 5 kW/5200rpm (approx. 52 hp)
- Maximum torque: 83 N·m/3000-3500rpm
- Combustion form: multi-sphere combustion chamber
- Fuel: 92 # gasoline
- Emission standard: G3/EU 2. The version with obd is Guo IV.
- Ignition sequence: 1-3-4-2
- Net mass: approx. 129 kg
Structure and characteristics
1. Cast iron cylinder body + aluminum alloy cylinder head, simple structure, strong versatility of accessories, low maintenance cost, huge domestic ownership.
2. Middle rear-drive layout, suitable for minibus and minivan; suitable for urban short-distance and light-load transportation.
3. Low speed torque is OK, high speed output
