4G15V Gasoline Engine with 1.5L Displacement SOHC 16-valve and China IV/V Emission Standard for Passenger Cars

10
MOQ
3300
Price
4G15V Gasoline Engine with 1.5L Displacement SOHC 16-valve and China IV/V Emission Standard for Passenger Cars
Features Gallery Product Description Chat Now
Features
Specifications
Cylinder Block: Alloy Cast Iron
CYLINDER BLOCK: LRON OR ALUMINUM
CYLINDER HEAD: ALUMINUM OR PLASTIC
Compressionratio: 10.5:1
Transmissioncompatibility: 6-Speed Automatic
Coolingsystem: Liquid Cooled
Aspiration: Naturally Aspirated
Numberofcylinders: 6
Engineblockmaterial: Aluminum
Enginetype: V6
Valvetrain: DOHC
Emissionstandard: Euro 6
Ignitionsystem: Electronic
Fuelinjection: Direct Injection
Fueltype: Gasoline
Horsepower: 280 HP
Torque: 260 Lb-ft
Highlight:

1.5L Displacement 4G15V Engine

,

SOHC 16-valve Gasoline Engine

,

China IV/V Emission Standard Inline 4-cylinder Engine
Basic Infomation
Place of Origin: CHONGQING
Brand Name: LINXIANG,WULING
Certification: ISO
Model Number: 4G15V
Payment & Shipping Terms
Packaging Details: export packaging
Delivery Time: 10DAY
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Product Description
4G15V Gasoline Engine
Model: 4G15V
Type: Inline 4-cylinder, 4-stroke, water-cooled, SOHC 16-valve gasoline engine
Displacement: 1.5L (1499cc)
Application: Primarily matched with passenger cars, small SUVs, and mini vans from brands including Soueast Mitsubishi, Zotye, Jinbei, and others.
Core Specifications
Bore * Stroke 75.5mm * 82.0mm
Compression Ratio 9.5:1 / 10.0:1 (varies by version)
Max. Power 77kW (105PS) @ 6000rpm
Max. Torque 134N·m @ 4500rpm
Fuel Supply Multi-point Injection (MPI)
Emission Standard National IV / National V (upgradable to National VI)
Firing Order 1-3-4-2
Key Features & Benefits
  • Compact Structure: Cast iron cylinder block with aluminum alloy cylinder head provides optimal balance between durability and lightweight design. Compact overall dimensions facilitate easy engine compartment layout.
  • Fuel Efficiency: SOHC valve train combined with optimized combustion design delivers strong low-speed torque and excellent fuel economy, particularly suited for urban driving conditions.
  • Reliability & Durability: Built on the mature Mitsubishi 4G1 series platform technology, offering low maintenance costs and high parts compatibility. Suitable for both commercial and household applications.
  • Wide Adaptability: Compatible with 5MT/4AT transmissions, supports front-transverse front-wheel drive layout, and can adapt to various vehicle chassis requirements.
This engine represents a proven, efficient power solution for compact vehicles, combining Mitsubishi's engineering heritage with modern performance requirements.
