4G15S Engine 1.5L Displacement SOHC 16-Valve Inline 4-Cylinder Engine with China IV/V Emission Standard

10
MOQ
3150 /units
Price
4G15S Engine 1.5L Displacement SOHC 16-Valve Inline 4-Cylinder Engine with China IV/V Emission Standard
Features Gallery Product Description Chat Now
Features
Specifications
Cylinder Block: Alloy Cast Iron
CYLINDER BLOCK: LRON OR ALUMINUM
CYLINDER HEAD: ALUMINUM OR PLASTIC
Compressionratio: 10.5:1
Transmissioncompatibility: 6-Speed Automatic
Coolingsystem: Liquid Cooled
Aspiration: Naturally Aspirated
Numberofcylinders: 6
Engineblockmaterial: Aluminum
Enginetype: V6
Valvetrain: DOHC
Emissionstandard: Euro 6
Ignitionsystem: Electronic
Fuelinjection: Direct Injection
Fueltype: Gasoline
Horsepower: 280 HP
Torque: 260 Lb-ft
Highlight:

1.5L Displacement 4G15S Engine

,

SOHC 16-Valve Cylinder Block and Head Assembly

,

China IV/V Emission Standard Inline 4-Cylinder Engine
Basic Infomation
Place of Origin: CHONGQING
Brand Name: LINXIANG,WULING
Certification: ISO
Model Number: 4G15S
Payment & Shipping Terms
Packaging Details: export packaging
Delivery Time: 10DAY
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Product Description
4G15S Gasoline Engine
Engine Specifications
Model: 4G15S
Type: Inline 4-cylinder, 4-stroke, water-cooled, SOHC 16-valve gasoline engine
Displacement: 1.5L (1499cc)
Primary Application: Passenger cars, small SUVs, and mini vans for brands including Soueast Mitsubishi, Hafei, Brilliance Jinbei, and others.
Core Technical Specifications
Bore * Stroke 75.5mm * 82.0mm
Compression Ratio 9.5:1
Max. Power 76kW (103PS) @ 6000rpm
Max. Torque 130N·m @ 4500rpm
Fuel Supply System Multi-point Injection (MPI)
Emission Standard National IV / National V
Firing Order 1-3-4-2
Key Features & Benefits
  • Proven Reliability: Derived from Mitsubishi's classic 4G1 series platform with simple, durable construction, low maintenance costs, and high parts compatibility. A mainstream power solution for entry-level vehicles in China.
  • Excellent Fuel Efficiency: SOHC valve train combined with optimized combustion chamber design delivers strong low-speed torque and outstanding fuel economy in urban driving conditions, ideal for daily family use and commercial operations.
  • Compact Design: Cast iron cylinder block with aluminum alloy cylinder head provides optimal strength-to-weight ratio. Compact overall dimensions facilitate easy engine compartment layout in front-transverse FWD vehicles.
  • Broad Compatibility: Compatible with 5MT manual transmissions and adaptable to various chassis and body configurations. Suitable for sedans, SUVs, mini vans, and multiple vehicle types.
Tag:

Cylinder Head

Engine Block

Engine Block Head
