CB10 engine 1.0L gasoline engine with 999 mL displacement DOHC 16-valve and aluminum alloy head for urban logistics

10
MOQ
1950/ units
Price
CB10 engine 1.0L gasoline engine with 999 mL displacement DOHC 16-valve and aluminum alloy head for urban logistics
Features Gallery Product Description Chat Now
Features
Specifications
Cylinder Block: Iron Casting
CYLINDER BLOCK: LRON OR ALUMINUM
CYLINDER HEAD: ALUMINUM OR PLASTIC
Compressionratio: 10.5:1
Transmissioncompatibility: 6-Speed Automatic
Coolingsystem: Liquid Cooled
Aspiration: Naturally Aspirated
Numberofcylinders: 6
Engineblockmaterial: Aluminum
Enginetype: V6
Valvetrain: DOHC
Emissionstandard: Euro 6
Ignitionsystem: Electronic
Fuelinjection: Direct Injection
Fueltype: Gasoline
Horsepower: 280 HP
Torque: 260 Lb-ft
Highlight:

999 mL displacement CB10 engine

,

DOHC 16-valve 1.0L gasoline engine

,

aluminum alloy head inline four-cylinder engine
Basic Infomation
Place of Origin: CHONGQING
Brand Name: LINXIANG,WULING
Certification: ISO
Model Number: CB10
Payment & Shipping Terms
Packaging Details: export packaging
Delivery Time: 10DAY
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 200 units will be delivered within 15 days
Product Description
CB10 Engine Overview
The CB10 is a classic 1.0L inline four-cylinder, 16-valve DOHC gasoline engine developed by Changan, widely used in microcars like the Changan Star and Changan Star Truck, as well as some small commercial vehicles.
Basic Specifications
Displacement 999 mL
Bore * Stroke 66 mm * 73 mm
Compression Ratio 10:1
Maximum Power 51 kW (≈69 hp) @ 6000 rpm
Maximum Torque 92 N*m @ 4000-4500 rpm
Valvetrain DOHC 16V, multi-point fuel injection
Fuel Requirement 92-octane or higher unleaded gasoline
Emission Standard National IV / National V (depending on model year and calibration)
Structure & Technical Features
  • Cylinder Block & Head: Cast iron block + aluminum alloy head for good heat dissipation and light weight. The cylinder head features an integrated exhaust manifold to improve thermal management efficiency.
  • Lubrication & Cooling: Full-pressure lubrication system with a gear-type oil pump, and a water-cooled system with a thermostat for precise temperature control.
  • Ignition & Fuel System: Electronic ignition with a distributorless design and multi-point sequential fuel injection, ensuring stable combustion and good fuel economy.
  • Noise & Vibration: Optimized crankshaft and balance shaft design, along with a timing chain (or belt) drive system, to reduce NVH (noise, vibration, harshness) and improve durability.
Application & Performance
Typical Applications: Changan Star series, Changan Star Truck, and other small commercial vehicles.
Key Strengths: Compact structure, reliable performance, low fuel consumption, and easy maintenance, making it ideal for urban logistics and light-duty transportation.
Service Life: With proper maintenance, the engine can typically achieve a service life of over 300,000 km.
