F8CV SOHC 0.8L Three Cylinder Naturally Aspirated Gasoline Engine

10
MOQ
1700/UNTI
Price
F8CV SOHC 0.8L Three Cylinder Naturally Aspirated Gasoline Engine
Features Gallery Product Description Chat Now
Features
Specifications
CYLINDER BLOCK: LRON OR ALUMINUM
CYLINDER HEAD: ALUMINUM OR PLASTIC
Compressionratio: 10.5:1
Transmissioncompatibility: 6-Speed Automatic
Coolingsystem: Liquid Cooled
Aspiration: Naturally Aspirated
Numberofcylinders: 6
Engineblockmaterial: Aluminum
Enginetype: V6
Valvetrain: DOHC
Emissionstandard: Euro 6
Ignitionsystem: Electronic
Fuelinjection: Direct Injection
Fueltype: Gasoline
Horsepower: 280 HP
Torque: 260 Lb-ft
Highlight:

SOHC 0.8L Three Cylinder Engine

,

Naturally Aspirated Compact Gasoline Motor

,

F8CV
Basic Infomation
Place of Origin: CHONGQING
Brand Name: LINXIANG,WULING
Certification: ISO
Model Number: F8CV
Payment & Shipping Terms
Packaging Details: export packaging
Delivery Time: 10DAY
Payment Terms: L/C,D/P,D/A,T/T,Western Union
Product Description

1. Brief Introduction F8CV is an inline 3-cylinder, 0.8L naturally aspirated gasoline engine originally developed by Daewoo, widely matched on Daewoo Matiz, Tico, Damas and Chevrolet Spark (Lechi 0.8L), mature compact power unit for mini hatchback & small commercial vans, compliant with Euro 2/Euro 3/Euro 4 emission standard. Cast iron cylinder block + aluminum cylinder head design features stable performance, low fuel consumption and affordable maintenance cost, huge aftermarket demand for replacement engine. 2. Core Technical Data

ItemSpecification
ModelF8CV 0.8L Three-Cylinder NA Gasoline Engine
ConfigurationInline 3-Cylinder (I3)
Valve StructureSOHC, 6 Valves (2 valves per cylinder)
Bore × StrokeΦ68.5 mm × 72 mm
Displacement796 cc (0.8L)
Rated Power38 kW (52 HP) @ 6000 rpm
Maximum Power40 kW (55 HP) @ 5900 rpm (net)
Peak Torque69 N·m @ 3500 rpm
Compression Ratio9.3:1
Fuel Grade90# / 92# Unleaded Gasoline
Engine Net Weight68 kg
Recommended Engine Oil5W-30 (3.2L capacity)
Emission StandardChina National III / IV; Euro III / IV
Cylinder Block MaterialCast Iron
Cylinder Head MaterialAluminum Alloy
Timing MechanismTiming Belt (replacement every 60,000 km recommended)
Firing Order1-2-3
Cooling SystemWater-Cooled, Forced Circulation
